+ Stable operation:
- Complying with global industry standards as ISO9001, API672 and customer specific requirements
- 100% Oil-Free compressed air without any contamination: ISO 8573-1 Class 0 certification
- ISO 8573-1 specifies purity classes of compressed air with respect to particles, water and oil independent of the location in the compressed air system at which the air is specified or measured
- Using three-dimensional design system to eliminate potential design flaws in the design phase
- Thorough quality control system to reduce any risk exposure
- The fastest growing in the industry since 1997
- Certified by major players in various industries in the Middle East, Europe, Americas, etc.
+ Budget savings:
- High efficiency oriented components and low maintenance design will provide customers with lower life-cycle cost.
- Flexible IGV adjusting the flow rate in accordance with the fluctuation of air consumption to reduce energy consumption up to 7%.
- Wear resistance materials as stainless steel for minimizing abrasion and corrosion.
- Precise 5-Axis machined impeller and long life guaranteed oil and gas seals.
- Simple and no wearing structure leads minimized maintenance effort and cost.
- Energy saving analysis to diagnose current status and find the root cause of energy waste can minimize the unnecessary cost and keep customers’ profit high.
+ Risk minimization:
- Preventive maintenance program provides a guideline or an actual check service for keeping customer’s equipment healthy.
- Remote Monitoring System does daily check of customer’s equipment, and provides prompt alarm / notification service once any problem happens.
- RUSH112 service and wide range of service network minimizes downtime when emergency situation occurs.1. Optimized design to maximize customer benefit:
Low maintenance and highly efficient design play a key role to maximize customer profit
+ Energy Saving Inlet Guide Vane:
- Precise control of air flow by efficient inlet air control.
- Reduction of power consumption through partial load control.
+ Durable Coolers:
- Water-in-tube inter & aftercooler bundles allow simple maintenance and easy cleaning.
- Corrosion / erosion resistant material applied for protecting damage of other components.
- Minimizing pressure drop by optimized airflow.
- Low pressure loss with airfoil profiled vanes.
+ Simple & Neat Package:
- Complete full package for plug & run provides easy and low-cost installation.
- Full enclosure is applicable for clean appearance and quiet operation which creates a comfortable work environment (Low noise with sound enclosure)
- Minimizing maintenance cost by simple structure.
+ Leak-Free Lubrication System:
- Minimum air leakage reduces losses and increases overall efficiency
- Leakproof gearbox prevents impurities from entering the process
- Complete lubrication system package (Including Oil reservoir, Auxiliary oil pump, Oil heater, Oil demister)
+ Maintenance Friendly Gearbox:
- Easy maintenance by horizontally split structure
- Minimum cost for inspection and maintenance
+ Highly Efficient Main Drive Motor;
- Highly efficient package saves energy
- Custom motors are available reflecting client requirements (option)
2. Concentrating on efficiency with reliability:
Core Unit is the heart of SM Series to achieve high efficiency and reliability by strictly selected optimized components and simple design
+ State-of-the-art 5-Axis Machined Impeller:
- Precisely balanced and designed for stability and high efficiency
- Wide operational flexibility with turndown ratio of 30-40%
- 115% over-speed spin test to guarantee reliability
- SUS impellers for extended life cycle with low vibration and low noise
+ Long Life Thrust Bearing:
- Tilting pad journal bearings applied on pinion gears offer reliable operation and almost permanent life without replacement.
- Low friction loss sleeve journal and taper landed thrust bearings are applied on bull gear.
+ Precise Bull Gear and Pinions:
- High precision gear system provides long-life time, low vibration and low noise.
- Taper land bearings effectively support axial loads delivered from pinion gears that improve stability of rotation and efficiency.
- Easy inspection of gear system without stage disassembly.
+ Leak-Free Oil & Gas Seals:
- Supplies 100% oil-free air in accordance with ISO8573-1 class zero for minimizing loss from downtime.
- 4 stages of sealing which satisfies API specification.
- Split structure for easy check and maintenance.
3. Specifications:
